Hand pumps
PM 12-25-45 byB-AISI-316 (VMQ)
DETAILS
with release hand knob
with pressure relief valve
double acting hand pump for single acting cylinder for fixing to tank
SPECIFICATIONS
Stainless steel AISI 316 pump body
Stainless steel AISI 630 piston rod with Niploy coating (50 μm)
Silicon seals (VMQ)
Lever connection Ø 27
Stainless steel AISI 316 external parts
Oil tank mounting kit including
Equipped with non return valve on the
outlet port
Triple sealing system made to prevent
any oil leakage and sweating onto the piston rod
On Demand ATEX Certificates
II2G Ex h IIB TX Gb
II2D Ex h IIIB TX Db
|
EFFORT DIAGRAM
|
|
